Product Name

molybdenum tube

Material

pure molybdenum or molybdenum alloy

Size

reference the below details

Model Number

Mo1 Mo2

Surface

hot rolling, cleaning, polished

Delivery time

10-15 working days

MOQ

1 kilograms

Used

Aerospace industry, Chemical equipment industry

The specification would be changed by the customers' requirements.

Diameter (mm)

Wall thickness (mm)

Length (mm)

30-50

2–10

<1000

50-100

3–15

100-150

3–15

150-200

5–20

200-300

8–20

300-400

8–30

400-450

8–30

450-500

8–30

Molybdenum tube

Density

Outer Dia

Length

Wall thickness

Forged Molybdenum tube

10.2g/cm3

5-150mm

≤800mm

≥1.0mm

Sintered Molybdenum tube

10.2g/cm3

100-500mm

≤800mm

 ≥5.0mm

Molybdenum products

Molybdenum plate/sheet/foil (min 0.05mm);

molybdenum rod/bar/wire; molybdenum tube

Molybdenum crucible,molybdenum boat/container,molybdenum tube.

Molybdenum heating element for vacuum furnace and high temperature furnace.

Molybdenum part made to required drawings.

Molybdenum alloy

TZM alloy,MoLa alloy. thermalcouple protection molybdenum tube

Tungsten products

Tungsten plate/sheet/foil (min 0.05mm); pure tungsten rod

Tungsten rod/bar/wire; thermalcouple protection molybdenum tu

Tungsten crucible,tungsten boat/container,tungsten tube.

Tungsten heating element for vacuum furnace and high temperature furnace.

Tungsten part made to customer's drawings.

Tungsten alloy

WCu alloy,WLa,WNiFe and WNiCu heavy alloy. molybdenum tube
